Product Principles
Servo electromechanical cylinders is a modular product that integrates the servo motor and ball screw, transmitting the rotational motion of the servo motor to the ball screw through components such as a reducer and synchronous wheel, and converting it into linear motion of a nut. At the same time, the precise speed control, precise revolution control, and precise torque control of the servo motor are transformed into precise speed control, precise position control, and precise thrust control, achieving a new revolutionary product in the high-precision linear motion series.
Product characteristics
The motor of the foldable electric cylinder is installed parallel to the electromechanical cylinder. The motor is connected to the transmission screw of the electric cylinder through a high-strength synchronous belt and synchronous pulley, which drives the screw to rotate. In addition to the characteristics of a linear electric cylinder, due to its short overall length, it is more suitable for situations with relatively small installation positions. The servo motor is connected to the electric cylinder as a whole, making it easy to install, set up, and use. In addition, the synchronous belt selected for the foldable electric cylinder has the characteristics of high strength, small clearance, and long service life, which makes the entire electric cylinder have high control performance and control accuracy.
Application scope
Servo electromechanical cylinders are widely used in aerospace experimental testing, multi degree of freedom simulation, multi degree of freedom dynamic entertainment, robots, mechanical lifting platforms, automotive presses, automotive manufacturing equipment, new energy motors, transportation tracks, textile machinery, military equipment, food and pharmaceutical machinery, and other fields.
Product Advantages
High performance
The servo electromechanical cylinders can work faultlessly in harsh environments, and achieve high intensity, high speed, and high-precision movement, smooth operation, low noise, and has precise guidance and anti rotation mechanisms inside, ensuring high-precision position control and high reliability of the equipment.
Flexibility
The electric electromechanical cylinder is a modular product that can provide very flexible installation configurations. The entire series of installation components include front flange, rear flange, horizontal base, rear hinge, front threaded flange, etc. It can be installed in line or parallel with the servo motor, and various accessories can be added: magnetic induction switch, grating ruler, pressure sensor, etc. The drive can choose from AC brake motor, DC motor, etc Stepper motors and servo motors of various brands.
Low maintenance costs
The servo electromechanical cylinder only needs to be lubricated regularly when working under complex working conditions, and there are no vulnerable parts that need to be maintained or replaced.
Environmental protection and energy conservation
Servo electromechanical cylinders can completely replace hydraulic cylinders and air cylinders, and have the advantages of being more environmentally friendly, energy-saving, and clean compared to hydraulic cylinders and air cylinders.
